Three phase self coupling step-down starting transformer - Product overview: The  three-phase self coupling step-down
starting transformer is suitable for AC 50Hz, rated voltage 380V, and rated output capacity 14KW-3000KW.

Technical:Starting Autotransformer

1200KVA - 4.16kV - oil insulated

o Rated power: 1200KVA

o Rated engine power: 1200KVA

o Starters per hour: 5 (five)

o Engine start time: 14 seconds

o Minimum interval between starts: 10

minutes

o Consecutive starters: 2 (two)

o Primary rated voltage: 4160V

o Number of phases: 3 (three)

o Secondary rated voltage:

3328/2704/2080V - (80% / 65% / 50%)

o Frequency: 60Hz

o Insulating material: mineral oil

o Pt-100 oil/copper sensors for remote

monitoring/indication of temperature.

It is often used for infrequent
step-down starting of large capacity squirrel cage asynchronous motors to improve the impact on the transmission network during motor
starting. Although it is an old-fashioned starting device, the use of its multiple tap depressurization can not only adapt to the needs of
various load starting, but also obtain larger starting torque. Its function is to use the characteristics of transformer depressurization to
reduce the starting current of the motor. Three phase self coupling step-down starting transformer - Applicable occasions: Suitable for
infrequent step-down starting of three-phase squirrel cage asynchronous motors with a power of 14KW-3000KW.
