11KV 400KVA Distribution Transformer S11-M-400/11-0.4  3phase power transformer

11KV Distribution Transformer,Oil immersed
Reference standards-CEI 76-DIN 42511
Place of installation-Outside
Type of transformer-Total filling
Cooling mode-ONAN
Nature of the dielectric- Mineral oil
Winding type MT-Copper wire
BT winding type-Flat copper wire
关注:0

Before Ordering,Pls confirm the technical specification with our sales first!

Collection
QTY:
  • 11KV 100KVA Distribution Transformer S11-M-100/11-0.4  3phase power transformer

    Reference standards-CEI 76-DIN 42511
    Place of installation-Outside
    Type of transformer-Total filling
    Cooling mode-ONAN
    Nature of the dielectric- Mineral oil
    Winding type MT-Copper wire
    BT winding type-Flat copper wire
            Rated capacity:100kva
     3phase 11kv oil immersed transformer
    Frequency-50HZ
    Primary winding voltage-11 KV +/- 2 x 2.5% (at No load); 11 KV +/- 2 x 2.5% (at load)
    Voltage Winding Secondary To No-Load-400V
    Highest voltage for hardware-12KV
    Isolation voltage BT ground-10KV
          Connection Group: DYN11

    • Model
      S11-M-100/11/0.4KV
